EVA film for encapsulating solar modules:
EVA（ Ethylene Vinyl Acetate Copolyme r）is used as the main raw material for EVA film which is for encapsulating solar modules. EVA film is produced by thermal processing and forming equipment when EVA is fully mixed with some modified accessory ingredients. EVA film is easy to handle for it is inviscid under room temperature .
When encapsulating solar modules , the processing requirements should be followed . From bottom to top, we place glass, EVA, solar cell, EVA and TPT(TPE, PET)，then all these will be put into the preheated laminator to be laminated and solidified. The solidified solar cell, after being fixed with aluminium alloy frame and terminal box and then being tested and packed, becomes the solar cell module.
Specification:
- Appearance：Our EVA film is Embossed Type.
- Thickness：Common thickness is 0.35mm，0.4mm 0.45mm 0.5mm
- Width：Common width: 550mm, 670mm, 680mm, 810mm, 1000mm.
- Length：Common length per roll is 150m.
Laminating and Solidifying Process conditions:
